Coater
특징
1. Compatible with deposition of W, Ti, Ni, Cr, and other materials.
2. Equipped with a magnetron sputtering head.
3. Microcomputer-controlled system for high-precision thin-film deposition.
4. Full Auto / Manual operation modes.
|
SPEC |
|
|
Target size & Sample Base |
Φ49mm / Φ70mm |
|
Operation of evacuation |
Automatic |
|
Sputtering System | DC Magnetron Sputtering |
|
High Voltage Power Supply |
0~5mA/0~3kV(system control) |
|
Gas regulating mechanism |
Needle valve(system control) |
|
Chamber Size |
160(Φ) X 160(D)mm (SUS) |
|
Dimensions and Weight |
Main unit : 360(W) X 422(D) X 265(H)mm, 20kg RP : 460.5(W) X 173.5(D) X 264(H)mm, 22.4kg |
Power Supply | Single Phase AC 100V 50/60Hz 10A |
